| Design |
for sensor LDL400 |
| Medium temperature |
0...80 |
| Pressure rating |
|
| Note on pressure rating |
| at medium temperature 20°C |
|
| Pressure equipment directive |
A possible classification to PED depends on the application and has to be carried out by the user / operator. |
| Safety instructions |
The compatibility between medium and product material has to be checked in all applications. |
| Weight |
131.1 |
| Materials (wetted parts) |
housing: PP-H; O-ring: EPDM |
| Sensor connection |
G 1 1/2 DIN ISO 228-1 |
| Process connection |
Welding adapter EN ISO 15494 DN32 Ø 40 mm |
| Items supplied |
|
| Pack quantity |
1 pcs. |
