| Design |
for flow sensors and compact flow monitors |
| Application |
for industrial applications |
| Installation |
via internal G1/8A male thread, any mounting position |
| Media |
liquids and gases |
| Medium temperature |
0...80; (Max. temperature gradient of medium: 1 K/min) |
| Pressure rating |
|
| Flow range |
2...100 |
| Pressure equipment directive |
A possible classification to PED depends on the application and has to be carried out by the user / operator. |
| Safety instructions |
The compatibility between medium and product material has to be checked in all applications. |
| Weight |
156.5 |
| Dimensions |
M12 x 1 |
| Thread designation |
M12 x 1 |
| Material |
stainless steel (1.4404 / 316L) |
| Sensor connection |
M12 x 1 |
| Process connection |
G 1/8 |
| Items supplied |
|
| Accessories (optional) |
| Adapter: ≤ 30 bar, E40101 | | Adapter: ≤ 300 bar, E40236 |
|
| Remarks |
| Can only be used in combination with the flow sensor’s relative operating mode. |
|
| Pack quantity |
1 pcs. |
