| Operating voltage |
26.5...31.6 DC |
| Electrical design |
AS-i |
| Contact rating |
< 4 A |
| Ambient temperature |
-25...85 |
| Protection |
IP 65 |
| Weight |
70.5 |
| Housing |
rectangular |
| Type of mounting |
Mounting on DIN rail and panel |
| Dimensions |
82.5 x 45 x 33 |
| Material |
PBT |
| Accessories (optional) |
| cover:, for AS-i module, AC3000 | | screw terminal insert:, AC5007 |
|
| Remarks |
| up to 4 M20 cable ports for any T and cross branches | | For DIN rail mounting pull the locking bolt outwards using a suitable tool (e.g. screwdriver). |
|
| Pack quantity |
1 pcs. |
|
screw terminals: ...2.5 mm² |
