| Protection | IP 67 |
| Material | housing: PA; O-ring: FKM; knurled nut: brass nickel-plated; contact pins: bronze tin-plated |
| Product designation | Flat cable insulation displacement connector |
| Ambient temperature | -25...70 |
Все характеристики
| Design | AS-i | ||
| Operating voltage | < 42 DC | ||
| Protection class | III | ||
| Max. current load total | 4 | ||
| Ambient temperature | -25...70 | ||
| Storage temperature | -25...75 | ||
| Protection | IP 67 | ||
| UL approval |
|
||
| Weight | 17.7 | ||
| Material | housing: PA; O-ring: FKM; knurled nut: brass nickel-plated; contact pins: bronze tin-plated | ||
| Remarks |
|
||
| Pack quantity | 1 pcs. | ||
| Connector: M12; coding: A; Tightening torque: 0.4...0.6 Nm |
Приемущества
| For transition from AS-i flat cable to M12 connector |
| For extending the AS-i network |
| Easy and quick connection due to insulation displacement technology |
| High protection rating for the requirements of harsh industrial environments |
