| Design |
housing for DIN rail mounting |
| Application |
Extension of the AS-i network by another 100 m |
| Operating voltage |
26.5...31.6 DC |
| Max. current consumption from AS-i |
60; (per AS-i line) |
| Electrical design |
AS-i |
| Electrically separated |
yes |
| Ambient temperature |
-25...70 |
| Note on ambient temperature |
|
| Storage temperature |
-25...75 |
| Max. relative air humidity |
90; (non condensing) |
| Max. height above sea level |
2000 |
| Protection |
IP 20 |
| Degree of soiling |
2 |
| EMC |
|
| UL approval |
| Ta | -25...70 °C | | Enclosure type | IP20 | | voltage supply | Low Voltage / Limited Energy | | File number UL | E205959 |
|
| Weight |
170 |
| Housing |
rectangular |
| Type of mounting |
Mounting on DIN rail; (TH35 (EN 60715)) |
| Dimensions |
125.7 x 25.4 x 108 |
| Material |
PA 6.6 |
| Display |
| Power | 2 x LED, green | | Function | LED, yellow |
|
| Items supplied |
| Combicon connector | | Link for bus termination |
|
| Pack quantity |
1 pcs. |
