| Application |
|
| Application |
Improvement of the signal quality |
| Electrical data |
|
| Nominal voltage DC |
26.5...31.6 |
| Max. current consumption from AS-i |
10 |
| Reverse polarity protection |
yes |
| Undervoltage monitor |
yes |
| Outputs |
|
| Electrical design |
AS-i |
| Electrically separated |
no |
| Operating conditions |
|
| Ambient temperature |
-25...70 |
| Storage temperature |
-25...70 |
| Storage humidity |
> 90; (non condensing) |
| Protection |
IP 67 |
| Tests / approvals |
|
| MTTF |
550 |
| Mechanical data |
|
| Weight |
45 |
| Dimensions |
Ø 20 / L = 46 |
| Displays / operating elements |
|
| Display |
<table><tr><td></td><td>1 x LED, yellow Voltage AS-i > 18,5 V</td></tr><tr><td></td><td>1 x LED, green Voltage AS-i > 26 V</td></tr></table> |
| Remarks |
|
| Remarks |
<table><tr><td> no addressing required</td></tr></table> |
| Pack quantity |
1 pcs. |
| Electrical connection |
|
