| Technical Data |
|
| Electrical control |
FieldbusIntegrated controller |
| Ambient temperature |
-550 |
| Storage temperature |
-2070 |
| Degree of protection |
IP65IP67 |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| CE mark (see declaration of conformity) |
To EU EMC DirectiveTo EU Explosion Protection Directive (ATEX)In accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) |
To UK instructions for EMCTo UK EX instructionsTo UK RoHS instructions |
| KC mark |
KC-EMV |
| Approval |
RCM trademarkc UL us - Recognized (OL) |
| Explosion protection |
Zone 2 (ATEX)Zone 2 (RU)Zone 2 (UKEX) |
| ATEX category gas |
II 3G |
| Explosion protection certification outside the EU |
EPL Gc (GB)EPL Gc (RU) |
| Explosion ignition protection type for gas |
Ex ec IIC T4 Gc X |
| Explosion ambient temperature |
-5 °C <= Ta <= +50 °C |
| LED display |
Bus statusChannel statusModule statusSystem status |
| Diagnosis |
Diagnostic memoryChannel-oriented and module-oriented diagnosticsUndervoltage of modules |
| Max. address volume, inputs |
64 |
| Max. address volume, outputs |
64 |
| Parameterisation |
Diagnostic behaviourFail-safe responseForcing of channelsSignal setup |
| Internal cycle time |
< 1 ms |
| Operational voltage range DC |
1830 |
| Nominal operating voltage DC |
24 |
| Max. power supply |
16 |
