SKU: 567417
GTIN: 4052568215347
Все характеристики
| Technical Data | |
| Dimensions (W x L x H) | 50 x 107 x 55 mm |
| Diagnosis | Channel-oriented and module-oriented diagnostics |
| Short circuit current rating | yes |
| Device-specific diagnostics | Undervoltage of modulesMeasuring system undervoltageVia local 7-segment display |
| Max. number of modules | 9 |
| Display | 7-segment display |
| Status displays | LED yellow = PL (power load)LED red = error |
| Operational voltage range DC | 1830 |
| Nominal operating voltage DC | 24 |
| Power failure bridging | 10 |
| Current consumption at nominal operating voltage | 80 |
| Approval | C-Tick |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -2070 |
| Relative air humidity | 5 - 95%Non-condensing |
| Degree of protection | IP65To IEC 60529 |
| Ambient temperature | -550 |
| Product weight | 140 |
| Axes per string | 1 |
| Number of axis strings | 1 |
| Max. cable length | 30 m |
| Electrical connection control interface | SocketM95-pin |
| Control-Interface | DigitalCAN bus with Festo protocol |
| Note on materials | RoHS-compliant |
| Material housing | PA-reinforced |
Приемущества
| Pneumatics and electrics – movement and measurement on one platform |
| Innovative measurement technology for piston rod drives, rodless drives, rotary drives |
| Control via fieldbus |
| Remote maintenance, remote diagnostics, web server, SMS and e-mail alerts are all possible via TCP/IP |
| Modules can be quickly exchanged and expanded without altering the wiring |
