SKU: 1577012

GTIN: 4052568242107

Все характеристики

Technical Data
Protocol	I-Port
Dimensions (W x L x H)	50 x 107 x 55 mm
Product weight	110
Ambient temperature	-550
Storage temperature	-2070
Degree of protection	IP65IP67
Corrosion resistance class CRC	1 - Low corrosion stress(when installed)
Max. cable length	20 m
LABS (PWIS) conformity	VDMA24364-B2-L
Note on materials	RoHS-compliant
Material housing	PA-reinforcedPC
LED display	- I-Port status/diagnosticsModule statusLoad supply statusSystem supply status
Diagnosis	Communication faultModule short circuitModule-orientated diagnosticsUndervoltage
Operator controls	DIL switch
Max. address volume, inputs	32
Max. address volume, outputs	32
Parameterisation	Diagnostic behaviourFail-safe per channelForcing per channelIdle mode per channelModule parametersTool-change mode
Internal cycle time	1 ms per 1 byte of user data
Additional functions	Tool-change mode
Electrical connection	4x socket5-pinA-codedM12
Operational voltage range DC	1830
Nominal operating voltage DC	24
Intern power consumption nominal operating voltage	Typ. 65 mA
Power failure bridging	10
Max. total output current per channel	4 x 1.6 A
Max. power supply per channel	4 x 1.6 A
Isolation channel - channel	no
Isolation channel - internal bus	Yes, with intermediate air supply
Number of device interfaces	4
