SKU: 2900543

GTIN: 4052568255534

Все характеристики

Technical Data
Protocol	IO-Link®
Dimensions (W x L x H)	50 x 107 x 55 mm
Product weight	110
Ambient temperature	-550
Storage temperature	-2070
Degree of protection	IP65IP67
Corrosion resistance class CRC	1 - Low corrosion stress(when installed)
Max. cable length	20 m
LABS (PWIS) conformity	VDMA24364-B2-L
Note on materials	RoHS-compliant
Material housing	PA-reinforcedPC
LED display	PS: Electronic supply, sensor supplyPL: Load supplyX1: System status IO-Link® port 1X1: System status of IO-Link at port 2Group diagnostics
Diagnosis	Communication faultModule short circuitModule-orientated diagnosticsUndervoltage
Operator controls	DIL switch
Max. address volume, inputs	32
Max. address volume, outputs	32
Parameterisation	Diagnostic behaviourFail-safe per channelForcing per channelIdle mode per channelModule parameters
Electrical connection	2x socket5-pinA-codedM12
Operational voltage range DC	1830
Nominal operating voltage DC	24
Intern power consumption nominal operating voltage	Typ. 65 mA
Power failure bridging	10
Isolation channel - channel	no
Isolation channel - internal bus	Yes, with intermediate air supply
IO-Link, Number of ports	2
IO-Link, Port class	AB
IO-Link, Protocol version	Master V 1.0
IO-Link, communication mode	COM1 (4.8 kB), COM2 (38.4 kB), COM3 (230.4 kB)
IO-Link, Process data length OUT	Parameterisable 4/4 to 16/16 bytes
IO-Link, Process data length IN	Parameterisable 4/4 to 16/16 bytes
IO-Link, Min. cycle time	Min. 1 ms per 1 byte of process data
IO-Link, Output current	1.6 A PL/port1.6 A PS/port
