SKU: 562214

GTIN: 4052568208974

Все характеристики

Technical Data
Ambient temperature	-550
Product weight	140
CE mark (see declaration of conformity)	To EU Low Voltage Directive
Degree of protection	IP65IP67
Storage temperature	-2070
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364-B2-L
Power failure bridging	10
Total number of axes	4
Dimensions (W x L x H)	50 x 107 x 55 mm
Control-Interface	CAN bus
Field bus interface	1x socket, M9, 5-pin
Device-specific diagnostics	Channel-oriented and module-oriented diagnosticsUndervoltage/short circuit of modulesDiagnostic memory
Configuration support	MMI handheld terminal
Parameterisation	Forcing of channelsSystem parameter
Baud rate	1 Mbps
Operational voltage range DC	1830
Nominal operating voltage DC	24
Protocol	FHPP
Intern power consumption nominal operating voltage	Typ. 80 mA
Max. address volume, outputs	32
Max. address volume, inputs	32
LED display, product-specific	ErrorPL: Load supply
Material housing	PA-reinforcedPC
