| Technical Data |
|
| Valve function |
2x3/2-way, monostable, closed |
| Valve size |
10 |
| Max. standard nominal flow rate |
10 l/min at 10 mm |
| pneumatic working port |
Sub-base |
| Operating pressure |
0116 |
| Approval |
c UL us - Recognized (OL) |
| KC mark |
KC-EMV |
| CE mark (see declaration of conformity) |
To EU EMC Directive |
| Signal status display |
LED |
| Suitability for vacuum |
no |
| Inrush time |
100 |
| Nominal pick-up current per solenoid coil |
55 mA to 100 ms |
| Nominal current with current reduction |
13 mA after 100 ms |
| Nominal operating voltage DC |
24 |
| Permissible voltage fluctuations |
+/- 10 % |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Media temperature |
-550 |
| Degree of protection |
IP40 |
| Pilot medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature |
-550 |
| Electrical control |
I-PortIO-Link®Multi-pin plug |
| Note on materials |
RoHS-compliant |
| Type of actuation |
Electric |
| Electrical I/O system |
yes |
| Terminal type |
84 |
| Max. number of valve positions |
24 |
| Valve terminal structure |
Fixed grid |
