| Technical Data |
|
| Valve function |
2/2-way, closed, monostable3/2-way, closed, monostable3/2 open, monostable |
| Valve size |
10 |
| Max. standard nominal flow rate |
10 l/min at 10 mm |
| pneumatic working port |
M3 |
| Operating pressure |
-0.98 |
| Approval |
c UL us - Recognized (OL) |
| CE mark (see declaration of conformity) |
In accordance with EU RoHS Directive |
| Certificate issuing authority |
UL MH19482 |
| Nominal size |
0.9 |
| Exhaust-air function |
With flow control option |
| Sealing principle |
Soft |
| Design |
Poppet valve with spring return |
| Type of reset |
Mechanical spring |
| Type of piloting |
Direct |
| Signal status display |
LED |
| Suitability for vacuum |
yes |
| Nominal operating voltage AC |
24 |
| Nominal operating voltage DC |
12 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Media temperature |
-540 |
| Degree of protection |
IP40IP65 |
| Ambient temperature |
-540 |
| Electrical control |
Individual connectionMulti-pin plug |
| Note on materials |
RoHS-compliant |
| Type of actuation |
Electric |
| Max. number of valve positions |
24 |
| Valve terminal structure |
Fixed grid |
