| Technical Data |
|
| Valve function |
Supply air one-way flow control function |
| Pneumatic connection, port 1 |
M3 |
| Pneumatic connection, port 2 |
M3 |
| Adjustment component |
Slotted head screw |
| Type of mounting |
Screw-in |
| Standard nominal flow rate in flow control direction |
18 |
| Standard nominal flow rate in blocked direction |
1820 |
| Operating pressure |
0.210 |
| Ambient temperature |
-1060 |
| Explosion protection |
The information in the certificate must be observed!Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Mounting position |
optional |
| Symbol |
00991453 |
| Standard flow rate in flow control direction 0.6->0 MPa (6->0 bar, 87->0 psi) |
33 |
| Standard flow rate in non-return direction 0.6->0 MPa (6->0 bar, 87->0 psi) |
3337 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Cleanroom class |
Class 4 according to ISO 14644-1 |
| Media temperature |
-1060 |
| Max. tightening torque |
0.3 |
| Product weight |
2 |
| Material screwed plug |
BrassNickel-plated |
| Note on materials |
RoHS-compliant |
| Material seals |
NBR |
| Material adjusting screw |
Brass |
| Material swivel fitting |
Die-cast zinc |
