SKU: 11968

GTIN: 4052568111953

Все характеристики

Technical Data
Valve function	3/2-way, closed, monostable
Type of actuation	Electric
Construction width	68
Standard nominal flow rate (standardised to DIN 1343)	7500
pneumatic working port	G3/4
Operating voltage	Via solenoid coil, must be ordered separately
Operating pressure	-0.9510
Design	Poppet seat
Type of reset	Mechanical spring
Approval	c UL us - Recognized (OL)
Degree of protection	IP65
Nominal size	19
Exhaust-air function	With flow control option
Sealing principle	Soft
Mounting position	optional
Manual override	Detenting
Type of piloting	Pilot actuated
Pilot air supply	External
Flow direction	Reversible
Symbol	00992879
lap	Underlap
Pilot pressure	18
Switching time off	32
Switching time on	36
Max. positive test pulse with 0 signal	2200
Characteristic coil data	See solenoid coil, to be ordered separately
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC	1 - Low corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
Storage temperature	-2060
Media temperature	-1060
Pilot medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Ambient temperature	-540
Product weight	1260
Electrical connection	Via F coil, to be ordered separately
Type of mounting	Either:On manifold railWith through-hole
Pilot exhaust port 82	M5
Pilot air port 12	G1/8
Pneumatic connection, port 1	G3/4
Pneumatic connection, port 2	G3/4
Pneumatic connection, port 3	G3/4
Note on materials	RoHS-compliant
Material seals	NBR
Material housing	Die-cast aluminium
