| Technical Data |
|
| Valve function |
3/2-way, closed, monostable |
| Type of actuation |
Electric |
| Operating pressure |
-13.05116 |
| Design |
On/off valve |
| Type of reset |
Mechanical spring |
| CE mark (see declaration of conformity) |
To EU Explosion Protection Directive (ATEX) |
| Explosion protection certification outside the EU |
EPL Da (CN)EPL Da (IECEx)EPL Ga (CN)EPL Ga (IEC-EX) |
| Certificate issuing authority |
ATEX: CML 17 ATEX 2046XIEC: IECEx CML 17.0030X |
| ATEX category gas |
II 1G |
| ATEX category dust |
II 1D |
| Explosion ignition protection type for gas |
Ex ia IIC T6...T5 Gb |
| Explosion ignition protection type for dust |
Ex ia IIIC T135°C Db |
| Explosion ambient temperature |
-40 °C<=Ta<=50 °C/65 °C |
| Degree of protection |
IP65 |
| Manual override |
Non-detenting |
| Flow direction |
Non-reversible |
| Symbol |
00991308 |
| Duty cycle |
100% |
| Insulation material class |
H |
| Max. input power Pi |
-55°C ~+50°C T6 = 2.98W-55°C ~+65°C T5 = 1W-55°C ~+65°C T5 = 2.98W-55°C ~+65°C T6 = 1W |
| Max. input voltage Ui |
31 V |
| Max. input current Ii |
0.67 A |
| Characteristic coil data |
24 V DC: 1.5 W |
| Effective internal inductivity Li |
Negligibly low |
| Effective internal capacitance Ci |
Negligibly low |
| Permissible frequency fluctuations |
+/- 10% |
| Explosion protection |
Zone 0 (ATEX)Zone 0 (CN)Zone 0 (IEC-EX)Zone 1 (ATEX)Zone 2 (ATEX)Zone 20 (ATEX)Zone 20 (CN)Zone 20 (IEC-EX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC |
2 - Moderate corrosion stress |
| LABS (PWIS) conformity |
VDMA24364 zone III |
| Ambient temperature |
-5580 |
| Type of mounting |
CNOMO |
| Note on materials |
RoHS-compliant |
