| Technical Data |
|
| Valve function |
3/2-way, closed, monostable |
| Type of actuation |
Electric |
| Operating pressure |
-13.05116 |
| Design |
On/off valve |
| Type of reset |
Mechanical spring |
| CE mark (see declaration of conformity) |
To EU Explosion Protection Directive (ATEX) |
| Explosion protection certification outside the EU |
EPL Db (CN)EPL Db (IEC-EX)EPL Gb (CN)EPL Gb (IECEx) |
| Certificate issuing authority |
ATEX: CML 15 ATEX 1119XCCC-Ex: 2020322307001701IEC: IECEx CML 17.0147X |
| ATEX category gas |
II 2G |
| ATEX category dust |
II 2D |
| Explosion ignition protection type for gas |
ATEX: Ex db IIC T5 GbCCC-Ex: Ex d IIC T3/T6 Gb |
| Explosion ignition protection type for dust |
Ex tb IIIC T100°C Db |
| Explosion ambient temperature |
ATEX: -65°C <= Ta <= +55°CCCC-Ex: -20 C <= Ta <= +40 °C |
| Degree of protection |
IP66 |
| Manual override |
Detenting |
| Flow direction |
Non-reversible |
| Symbol |
00991308 |
| Duty cycle |
100% |
| Insulation material class |
H |
| Characteristic coil data |
24 V DC: 3.0 W |
| Permissible frequency fluctuations |
+/- 10% |
| Explosion protection |
Zone 1 (ATEX)Zone 1 (CN)Zone 1 (IEC-EX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 21 (CN)Zone 21 (IEC-EX)Zone 22 (ATEX) |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC |
2 - Moderate corrosion stress |
| LABS (PWIS) conformity |
VDMA24364 zone III |
| Ambient temperature |
-2080 |
| Type of mounting |
CNOMO |
| Note on materials |
RoHS-compliant |
