Technical Data
Design	Piloted piston poppet valve
Type of actuation	Pneumatic
Sealing principle	Soft
Mounting position	optional
Type of mounting	With accessories
Valve function	Proportional 3/3-way valve
Mode of operation	Single-acting
Operating pressure	20.3116
Type of reset	Mechanical spring
Pneumatic connection	Sub-base design, airing
Operating medium	Compressed air to ISO 8573-1:2010 [7:7:-]Inert gases
Note on operating and pilot medium	Lubricated operation not possible
Media temperature	-4080
Ambient temperature	-4080
Standard nominal flow rate (standardised to DIN 1343)	1240
C value	5.58
b value	0.214
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364 zone III
Material housing	Smooth-anodised wrought aluminium alloy (20 µm)
Material cover	Smooth-anodised wrought aluminium alloy (20 µm)
Material seals	EPDMNBR
Material screws	High-alloy stainless steel
Material spring	Spring steel
Product weight	1560
Explosion protection	Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX)
Corrosion resistance class CRC	3 - high corrosion stress
