SKU: 8141660

GTIN: 4052568580513

Все характеристики

Technical Data
Design	Piloted piston poppet valve
Type of actuation	Pneumatic
Sealing principle	Soft
Mounting position	optional
Type of mounting	With accessories
Valve function	4/2-way, monostableFail safe
Mode of operation	Double-acting
Operating pressure	47.85116
Type of reset	Mechanical spring
Pneumatic connection	Sub-base design, airing
Pneumatic connection, port 1	G1/2
Operating medium	Compressed air to ISO 8573-1:2010 [7:7:-]Inert gases
Note on operating and pilot medium	Lubricated operation not possible
Media temperature	-2080
Ambient temperature	-2080
Standard nominal flow rate (standardised to DIN 1343)	1093
Note on materials	RoHS-compliant
LABS (PWIS) conformity	VDMA24364 zone III
Material housing	Smooth-anodised wrought aluminium alloy (20 µm)
Material cover	Smooth-anodised wrought aluminium alloy (20 µm)
Material seals	EPDMNBR
Material screws	High-alloy stainless steel
Material spring	Spring steel
Product weight	880
Explosion protection	Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX)
Corrosion resistance class CRC	3 - high corrosion stress
