SKU: 9084
GTIN: 4052568020354
Характеристики
| Outside diameter | 6 |
| Inside diameter | 3.92 |
| Material tubing | Wrought aluminium alloy, PE |
| Temperature-dependent operating pressure | -0.95, 30 |
| Ambient temperature | -29, 65 |
Все характеристики
| Technical Data | |
| Outside diameter | 6 |
| Flow-relevant bending radius | 19 |
| Inside diameter | 3.92 |
| Temperature-dependent operating pressure | -0.9530 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -2965 |
| Product weight according to length | 0.024 |
| Colour | Black |
| Note on materials | RoHS-compliant |
| Material tubing | Wrought aluminium alloyPE |
Приемущества
| Polyethylene, aluminium |
| Can be bent straight and reshaped several times without a pipe-bending device and without being damaged |
| Resistant to deformation |
| Operating medium: compressed air, vacuum |
