SKU: 177717
GTIN: 4052568075620
Все характеристики
| Technical Data | |
| Nominal size | 18.6 |
| Mounting position | optional |
| Size of pack | 1 |
| Operating pressure complete temperature range | -0.957 |
| Temperature-dependent operating pressure | -0.9515 |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Media temperature | -2575 |
| Ambient temperature | -2570 |
| Nominal torque | 2.5 |
| Tolerance for nominal tightening torque | ± 10% |
| Number of outputs | 4 |
| Number of supply lines | 1 |
| Pneumatic connection, port 1 | Female thread G1/2 |
| Pneumatic connection, port 2 | Female thread G1/2 |
| Note on materials | RoHS-compliant |
| Material housing | POM |
