| Technical Data |
|
| Size |
Standard |
| Nominal size |
6.5 |
| Mounting position |
optional |
| Design |
Push-pull principle |
| Size of pack |
10 |
| Operating pressure complete temperature range |
-13.775145 |
| Maritime classification |
See certificate |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium |
Lubricated operation possible |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Ambient temperature |
23140 |
| Product weight |
10.9 |
| Type of mounting |
Mounting pin |
| Pneumatic connection, port 1 |
Cartridge 18 mm |
| Pneumatic connection, port 2 |
For tubing outside diameter of 3/8" |
| Colour of release ring |
grey |
| Note on materials |
RoHS-compliant |
| Material housing |
PA-reinforced |
| Material release ring |
POM |
| Material tubing seal |
NBR |
| Material tubing clamp component |
High-alloy stainless steel |
