| Technical Data |
|
| Nominal size |
5 |
| Operating pressure complete temperature range |
-13.775174 |
| Standard nominal flow rate (standardised to DIN 1343) |
8751050 |
| Nominal flow rate standardised according to ISO 8778 |
948.51138.2 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium |
Lubricated operation possible |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Ambient temperature |
-1060 |
| Nominal torque |
3.5 |
| Tolerance for nominal tightening torque |
± 10% |
| Product weight |
94 |
| Pneumatic connection, port 1 |
Male thread G1/8 |
| Note on materials |
RoHS-compliant |
| Material seals |
NBR |
| Material spring |
High-alloy stainless steel |
| Material housing |
Brass, nickel-plated |
| Material thread seal |
PA66-GF30/TPE-U |
| Material thread piece |
Nickel-plated brass |
| Material of inner raceway |
POM |
| Material ball |
High-alloy stainless steel |
| Material pins |
High-alloy stainless steel |
| Valve body material |
Brass |
| Material releasing sleeve |
POMPPHigh-alloy stainless steel |
