| Technical Data |
|
| Nominal size |
2.9 |
| Operating pressure complete temperature range |
-13.775174 |
| Standard nominal flow rate (standardised to DIN 1343) |
252261 |
| Nominal flow rate standardised according to ISO 8778 |
273.2282.9 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium |
Lubricated operation possible |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Ambient temperature |
-1060 |
| Product weight |
26 |
| Pneumatic connection, port 1 |
For tubing outside diameter of 6 mmFor barbed fitting I.D. 4 mm with union nut |
| Material union nut |
Wrought aluminium alloy, anodised |
| Note on materials |
RoHS-compliant |
| Information on materials |
Brass, nickel plated |
