SKU: 5195381

GTIN: 4052568647209

Все характеристики

Technical Data
Conforms to standard	IEC 61754-24
Protocol	EthernetPROFINET FOC
Additional functions	Fulfils requirements according to AIDA
Frequency of connection	100
Cable outlet	Straight
Product weight	84
Optical connection 1, connection type	Plug
Optical connection 1, design	Rectangular
Optical connection 1, connection technology	SC-RJ to IEC 61754-24
Optical connection 1, number of pins/cores	2
Optical connection 1, occupied pins/wires	2
Optical connection 1, plug pattern	00995772
Optical connection 1, type of mounting	Push-pull with interlock against unintentional pulling
Optical connection 1, ferrule diameter	2.5
Optical connection 2, connection technology	Lock nut
Tightening torque	0.42
Wire diameter	0.981
Type of wire	Polymer fibre
Wavelength	650 nm
Fire test	UL94 V-0
Cable diameter	5.510
Degree of protection	IP65IP67
Note on degree of protection	In assembled state
Ambient temperature	-2570
Storage temperature	-4070
LABS (PWIS) conformity	VDMA24364-A1-L
Note on materials	RoHS-compliant
Corrosion resistance class CRC	1 - Low corrosion stress
Material housing	Die-cast zinc, nickel-plated
Housing colour	Silver
Material seals	NBRTPE
Ferrule material	Copper alloy
