SKU: 150261

GTIN: 4052568116460

Все характеристики

Technical Data
Conforms to standard	EN 60947-5-1
Symbol	00991471
Approval	CCC
CE mark (see declaration of conformity)	To EU Low Voltage Directive
UKCA marking (see declaration of conformity)	To UK regulations for electrical equipment
Explosion protection	The information in the certificate must be observed!Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX)
Note on materials	RoHS-compliant
Measured variable	Relative pressure
Measurement method	Pneumatic/electric pressure transducer
Pressure measuring range	-14.523.2
Operating pressure	-11.6
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature	-2080
Ambient temperature	-2080
Switching element function	Changeover switch
Max. switching frequency	3
Max. switching output voltage AC	250
Max. switching output voltage DC	125
Max. output current	5000
Min. load current	1 mA at 24 V10 mA at 10 V100 mA at 5 V
Utilisation category - inductive load	AC-14DC-13
Utilisation category - resistive load	AC-12DC-12
Electrical connection	Type APlugsTo DIN 43650Square design
Type of mounting	With through-hole
Mounting position	optional
Pneumatic connection	G1/8
Product weight	240
Material housing	Wrought aluminium alloy
Material switch contact	Silver
Switching status indication	Yellow LED
Setting range threshold value	-0.95-0.2
Setting range threshold value after conversion	0.161.6
Degree of protection	IP65
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364-B1/B2-L
