SKU: 152618

GTIN: 4052568010898

Все характеристики

Technical Data
Symbol	00991472
Approval	RCM trademark
CE mark (see declaration of conformity)	To EU EMC DirectiveIn accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)	To UK instructions for EMCTo UK RoHS instructions
Note on materials	RoHS-compliant
Measured variable	Relative pressure
Measurement method	Pneumatic/electric pressure transducer
Pressure measuring range	28
Operating pressure	08
Max. overload pressure	20
Operating medium	Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature	060
Ambient temperature	060
Switching element function	Changeover switch
Hysteresis	0.52
Max. switching frequency	3
Max. output current	2500
Operational voltage range DC	1030
Electrical connection 1, connection type	Screw terminal
Electrical connection 1, connector system	Screw terminal
Electrical connection 1, number of connections/cores	4
Type of mounting	Either:With through-holeWith H-rail
Mounting position	optional
Pneumatic connection	M5
Product weight	56
Material housing	PAPETPOM
Material membrane	NBR
Switching status indication	Yellow LED
Setting range threshold value	28
Degree of protection	IP20
Corrosion resistance class CRC	2 - Moderate corrosion stress
LABS (PWIS) conformity	VDMA24364 zone III
