SKU: 159259

GTIN: 4052568126544

Все характеристики

Technical Data
Symbol	00991472
CE mark (see declaration of conformity)	To EU Low Voltage Directive
UKCA marking (see declaration of conformity)	To UK regulations for electrical equipment
Measured variable	Relative pressure
Measurement method	Pneumatic/electric pressure transducer
Pressure measuring range	110
Operating pressure	110
Operating medium	Compressed air to ISO 8573-1:2010 [7:-:-]
Note on operating and pilot medium	Lubricated operation possible (in which case lubricated operation will always be required)
Media temperature	-2080
Ambient temperature	-20100
Switching element function	Changeover switch
Max. switching frequency	3
Max. switching output voltage AC	250
Max. switching output voltage DC	250
Max. output current	4000
Operational voltage range DC	12250
Electrical connection	4-pinPlugs
Type of mounting	Screw-in
Mounting position	optional
Pneumatic connection	G1/4
Product weight	138
Material housing	Galvanised steel
Material membrane	NBR
Setting range threshold value	110
Degree of protection	IP65
LABS (PWIS) conformity	VDMA24364-B1/B2-L
