| Technical Data |
|
| Design |
Round |
| Conforms to standard |
EN 60947-5-2 |
| Symbol |
00991702 |
| Approval |
RCM trademarkc UL us listed (OL) |
| CE mark (see declaration of conformity) |
To EU EMC DirectiveTo EU Low Voltage DirectiveIn accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) |
To UK instructions for EMCTo UK RoHS instructionsTo UK regulations for electrical equipment |
| Measuring principle |
Inductive |
| Rated operating distance |
15 |
| Assured operating distance |
12.15 |
| Reduction factors |
Aluminium = 0.35 - 0.5Stainless steel St 18/8 = 0.6 - 1.0Copper = 0.25 - 0.45Brass = 0.35 - 0.5Steel St 37 = 1.0 |
| Ambient temperature |
-2570 |
| Repetition accuracy |
0.3 |
| Switching output |
PNP |
| Switching element function |
N/O contact |
| Hysteresis |
0.452.25 |
| Max. switching frequency DC |
500 |
| Max. output current |
200 |
| Voltage drop |
1.8 |
| Short circuit current rating |
Pulsed |
| Operational voltage range DC |
1030 |
| Residual ripple |
10 % |
| No-load supply current |
15 |
| Reverse polarity protection |
For all electrical connections |
| Electrical connection |
3-wireCable |
| Cable length |
2.5 |
| Material cable sheath |
PVC |
| Material insulating sheath |
PVC |
| Size |
M30 |
| Type of mounting |
Via lock nut |
| Tightening torque |
5 |
| Mounting type |
Not flush |
| Product weight |
158 |
| Material housing |
PA-reinforced |
| Switching status indication |
Yellow LED |
| Ambient temperature with moving cable |
070 |
| Degree of protection |
IP65IP67 |
| Corrosion resistance class CRC |
4 - Very high corrosion stress |
| Additional information for sensor selection |
with standard sensing distance |
| Electrical output |
PNP |
| Selection of sensor design |
Polyamide housing |
