| Technical Data |
|
| Conforms to standard |
EN 60947-5-2 |
| Symbol |
00992830 |
| Approval |
RCM trademarkc UL us listed (OL) |
| CE mark (see declaration of conformity) |
To EU EMC DirectiveIn accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) |
To UK instructions for EMC (UK-E)To UK RoHS instructions (UK-R) |
| Rated operating distance |
2 |
| Assured operating distance |
1.62 |
| Reduction factors |
Aluminium = 0.4Stainless steel St 18/8 = 0.6Copper = 0.3Brass = 0.5Steel St 37 = 1.0 |
| Ambient temperature |
-2570 |
| Repetition accuracy with constant conditions |
0.1 mm |
| Switching output |
PNP |
| Switching element function |
N/C contact |
| Hysteresis |
0.18 |
| Max. switching frequency |
3000 |
| Max. output current |
200 |
| Voltage drop |
2 |
| Inductive protective circuit |
Integrated |
| Short circuit current rating |
Pulsed |
| Operational voltage range DC |
1030 |
| Residual ripple |
± 10% |
| No-load supply current |
10 |
| Reverse polarity protection |
For all electrical connections |
| Electrical connection 1, connection type |
Plugs |
| Electrical connection 1, connector system |
M12x1, A-coded to EN 61076-2-101 |
| Electrical connection 1, number of connections/cores |
4 |
| Electrical connection 1, type of mounting |
Screw-type lockNot rotatable |
| Electrical connection 1, compatible type of mounting |
Compatible with rotatable screw-type lock |
| Size |
M12x1 |
| Type of mounting |
Via lock nut |
| Mounting type |
Flush |
| Product weight |
30 |
| Material housing |
BrassPBTPNickel-plated |
| Switching status indication |
Yellow LED |
| Ambient temperature with moving cable |
-570 |
| Degree of protection |
IP65IP67 |
| Corrosion resistance class CRC |
2 - Moderate corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Additional information for sensor selection |
with standard sensing distance |
| Electrical output |
PNP |
| Selection of sensor design |
Standard |
