| Technical Data |
|
| Conforms to standard |
EN 60947-5-2 |
| Symbol |
00991703 |
| Approval |
RCM trademarkc UL us listed (OL) |
| CE mark (see declaration of conformity) |
To EU EMC DirectiveIn accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) |
To UK instructions for EMC (UK-E)To UK RoHS instructions (UK-R) |
| Rated operating distance |
10 |
| Assured operating distance |
8.1 |
| Reduction factors |
Aluminium = 1.0Stainless steel, 1 mm thick = 0.4Stainless steel, 2 mm thick = 0.8Copper = 0.85Brass = 1.3Steel St 37 = 1.0 |
| Ambient temperature |
-2570 |
| Switching output |
NPN |
| Switching element function |
N/O contact |
| Reproducibility of switching values FS |
0.5 |
| Hysteresis |
1.22 |
| Max. switching frequency |
200 |
| Max. output current |
200 |
| Voltage drop |
2 |
| Inductive protective circuit |
IntegratedOutput current < 100 mAAnd switching frequency < 10 Hz |
| Short circuit current rating |
Pulsed |
| Operational voltage range DC |
1030 |
| Residual ripple |
20% |
| No-load supply current |
17 |
| Reverse polarity protection |
For all electrical connections |
| Electrical connection 1, connection type |
Plugs |
| Electrical connection 1, connector system |
M12x1, A-coded to EN 61076-2-101 |
| Electrical connection 1, number of connections/cores |
4 |
| Electrical connection 1, type of mounting |
Screw-type lockNot rotatable |
| Electrical connection 1, compatible type of mounting |
Compatible with rotatable screw-type lock |
| Size |
M18 |
| Type of mounting |
Via lock nut |
| Mounting type |
Flush |
| Product weight |
53 |
| Material housing |
High-alloy steel |
| Switching status indication |
Yellow LED |
| Ambient temperature with moving cable |
-570 |
| Degree of protection |
IP67IP69K |
| Housing pressure resistance |
60 |
| Corrosion resistance class CRC |
2 - Moderate corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Additional information for sensor selection |
with increased sensing distance |
| Electrical output |
NPN |
| Selection of sensor design |
Stainless steel housing |
