| Technical Data |
|
| Design |
Round |
| Conforms to standard |
EN 60947-5-2 |
| Symbol |
00991703 |
| Approval |
RCM trademarkc UL us listed (OL) |
| CE mark (see declaration of conformity) |
To EU EMC DirectiveTo EU Low Voltage DirectiveIn accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) |
To UK instructions for EMCTo UK RoHS instructionsTo UK regulations for electrical equipment |
| Note on materials |
RoHS-compliant |
| Rated operating distance |
10 |
| Ambient temperature |
-3085 |
| Repetition accuracy |
0.55 |
| Switching output |
NPN |
| Switching element function |
N/O contact |
| Max. switching frequency DC |
2000 |
| Max. output current |
200 |
| Short circuit current rating |
Pulsed |
| Operational voltage range DC |
1030 |
| Reverse polarity protection |
For all electrical connections |
| Electrical connection |
3-pinM12x1Plugs |
| Material connector housing |
BrassChrome-plated |
| Size |
M30 |
| Mounting type |
Flush |
| Product weight |
100 |
| Material housing |
BrassChrome-plated |
| Switching status indication |
Yellow LED |
| Degree of protection |
IP68 |
| Immunity to magnetic fields |
Magnetic direct and alternating field |
| Immunity to surge |
0.8 |
| Corrosion resistance class CRC |
2 - Moderate corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Pollution degree |
3 |
| Additional information for sensor selection |
Reduction factor 1, resistant to magnetic fields |
| Selection of sensor design |
Standard |
