| Technical Data |
|
| Design |
Round |
| Conforms to standard |
EN 60947-5-2 |
| Symbol |
00991712 |
| Approval |
RCM trademarkc UL us listed (OL) |
| CE mark (see declaration of conformity) |
To EU EMC DirectiveTo EU Low Voltage Directive |
| Measuring principle |
Inductive |
| Rated operating distance |
4 |
| Assured operating distance |
3.24 |
| Reduction factors |
Aluminium = 0.6Stainless steel St 18/8 = 0.9Copper = 0.5Brass = 0.6Steel St 37 = 1.0 |
| Ambient temperature |
-2585 |
| Repetition accuracy |
0.2 |
| Switching output |
Non-contacting, 2-wire |
| Switching element function |
N/O contact |
| Hysteresis |
0.030.88 |
| Max. switching frequency DC |
900 |
| Max. switching frequency AC |
25 |
| Max. output current |
200 |
| Voltage drop |
8 |
| Min. load current |
5 |
| Short circuit current rating |
no |
| Operational voltage range AC |
20265 |
| Operational voltage range DC |
20320 |
| Mains frequency |
50 |
| No-load supply current |
1.5 |
| Reverse polarity protection |
For all electrical connections |
| Electrical connection |
2-wireCable |
| Cable length |
2.5 |
| Material cable sheath |
TPE-U(PUR) |
| Material insulating sheath |
PVC |
| Size |
M12 |
| Type of mounting |
Via lock nut |
| Tightening torque |
10 |
| Mounting type |
Not flush |
| Product weight |
90 |
| Material housing |
BrassPANickel-plated |
| Switching status indication |
Yellow LED |
| Ambient temperature with moving cable |
-550 |
| Degree of protection |
IP67 |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Additional information for sensor selection |
For DC and AC voltage |
| Electrical output |
Non-contacting, 2-wire |
| Selection of sensor design |
Standard |
