SKU: 150011

GTIN: 4052568068660

Все характеристики

Technical Data
Design	Round
Conforms to standard	DIN EN 60947-5-2
Symbol	00992153
Approval	RCM trademark
CE mark (see declaration of conformity)	To EU EMC DirectiveTo EU Low Voltage DirectiveIn accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)	To UK instructions for EMCTo UK RoHS instructionsTo UK regulations for electrical equipment
Measuring principle	Magnetic reed
Ambient temperature	-2060
Repetition accuracy	0.2
Switching output	Contacting, bipolarWithout LED function
Switching element function	N/O contact
Switch-on time	2
Switch-off time	0.05
Max. switching frequency	500
Max. output current AC	250
Max. output current DC	120
Max. switching capacity AC	10
Max. switching capacity DC	10
Voltage drop	4.5
Short circuit current rating	no
Overload protection	Not available
Operational voltage range AC	12250
Operational voltage range DC	12250
Reverse polarity protection	no
Electrical connection 1, connection type	Cable
Electrical connection 1, connector system	Open end
Electrical connection 1, number of connections/cores	2
Connection outlet orientation	In-line
Cable length	2.5
Material cable sheath	PVC
Type of mounting	With accessories
Tightening torque	0.8
Mounting position	optional
Product weight	70
Material housing	PETTPE-O
Switching status indication	Yellow LED
Degree of protection	IP67
Immunity to surge	4
LABS (PWIS) conformity	VDMA24364-B2-L
Pollution degree	3
