SKU: 30441

GTIN: 4052568113599

Все характеристики

Technical Data
Design	Block design
Based on standard	EN 60947-5-2
Symbol	00991153
Approval	RCM trademark
CE mark (see declaration of conformity)	To EU EMC DirectiveIn accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)	To UK instructions for EMCTo UK RoHS instructions
Special characteristics	Welding field resistantResistant to welding spatter
Note on materials	RoHS-compliant
Measured variable	Position
Measuring principle	Magneto-inductive
Ambient temperature	-2570
Repetition accuracy	0.2
Switching output	PNP
Switching element function	N/O contact
Hysteresis	0.11.5
Switch-on time	35
Switch-off time	20
Max. switching frequency	20
Max. output current	200
Max. switching capacity DC	6
Voltage drop	3
Inductive protective circuit	Adapted to MZ, MY, ME coils
Off-state current	0.01
Short circuit current rating	Pulsed
Overload protection	Available
Operational voltage range DC	1030
Residual ripple	10 %
Reverse polarity protection	For all electrical connections
Electrical connection 1, connection type	Plugs
Electrical connection 1, connector system	M12x1, A-coded to EN 61076-2-101
Electrical connection 1, number of connections/cores	3
Electrical connection 1, type of mounting	Screw-type lock
Electrical connection 1, connection pattern	00991168
Connection outlet orientation	In-line
Material electrical contact	Gold-plated brass
Type of mounting	With accessories
Mounting position	optional
Product weight	70
Material housing	PAPURDie-cast zinc
Ready status indication	Green LED
Switching status indication	Yellow LED
Degree of protection	IP67
Immunity to magnetic fields	50 - 60 HzAlternating magnetic field
LABS (PWIS) conformity	VDMA24364-B2-L
