SKU: 31008
GTIN: 4052568003838
Все характеристики
| Technical Data | |
| Design | Block design |
| Symbol | 00991600 |
| Explosion protection | Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Measuring principle | Magnetic |
| Operating pressure | 26 |
| Operating medium | Compressed air to ISO 8573-1:2010 [6:4:4] |
| Note on operating and pilot medium | Lubricated operation not possible |
| Ambient temperature | -1560 |
| Reproducibility of switching value | +/-0.2 mm |
| Switch-on time | 30 |
| Switch-off time | 25 |
| Type of mounting | With through-holeWith accessories |
| Valve function | 3/2 |
| Pneumatic connection | Barbed fitting PK-3 |
| Product weight | 14 |
| Material housing | BrassPAPOM |
| Switching status indication | Optical |
| Degree of protection | IP65 |
| LABS (PWIS) conformity | VDMA24364-B2-L |
Приемущества
| Measuring principle: magnetic |
| Pneumatic proximity sensor |
| Function: 3/2-way valve, normally closed |
| Pneumatic connection via barbed fitting for tubing I.D. 3 mm |
| Visual switching status indication |
Документы
| SMPO_1_EN.PDF |
| Datasheet |
