| Technical Data |
|
| Explosion protection |
The information in the certificate must be observed!Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Frequency of connection |
100 |
| Mounting position |
optional |
| Product weight |
33 |
| Electrical connection |
8-pinSpring-loaded terminalStraight plug |
| Operational voltage range DC |
030 |
| Current rating at 40° C |
12 |
| Immunity to surge |
4 |
| Connection cross section |
0.22.5 |
| Ambient temperature |
-4085 |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Note on materials |
RoHS-compliant |
| Pollution degree |
3 |
| Corrosion resistance class CRC |
2 - Moderate corrosion stress |
| Material housing |
PA |
| Housing colour |
Blue |
| Material electrical contact |
Copper alloyTin-plated |
