| Technical Data |
|
| Protocol |
PROFINET |
| Approval |
c UL us - Recognized (OL) |
| Certificate issuing authority |
UL E328433 |
| Additional functions |
Fulfils requirements according to AIDA |
| Frequency of connection |
100 |
| Cable outlet |
Straight |
| Product weight |
109 |
| Electrical connection 1, design |
Angular |
| Electrical connection 1, connection type |
Socket |
| Electrical connection 1, connector system |
Connection pattern PP, coding on pins 2 and 5 |
| Electrical connection 1, number of connections/cores |
5 |
| Electrical connection 1, used connections/cores |
5 |
| Electrical connection 1, type of mounting |
Push-pull with interlock against unintentional pulling |
| Electrical connection 1, connection pattern |
00995899 |
| Electrical connection 2, connector system |
Spring-loaded terminal |
| Operational voltage range DC |
024 |
| Current rating at 40° C |
16 |
| Immunity to surge |
4 |
| Cable fitting |
Pg13.5, hexagon size 22 mm |
| Cable diameter |
913 |
| Nominal cross section conductor |
0.752.5 |
| Conductor nominal cross section |
AWG18 - 13 |
| Degree of protection |
IP65IP67 |
| Note on degree of protection |
In assembled state |
| Ambient temperature |
-4085 |
| Storage temperature |
-4085 |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Note on materials |
RoHS-compliant |
| Fire test |
UL94 V-0 |
| Pollution degree |
3 |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| Material housing |
Die-cast zinc, nickel-plated |
| Housing colour |
Silver |
| Material seals |
NBRTPE-V |
| Material electrical contact |
Nickel-plated and gold-plated copper alloy |
