| Technical Data |
|
| Based on standard |
EN 61076-2-101EN 61984 |
| Explosion protection |
The information in the certificate must be observed!Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Frequency of connection |
50 |
| Mounting position |
optional |
| Product weight |
17 |
| Electrical connection 1, function |
Field device side |
| Electrical connection 1, design |
Round |
| Electrical connection 1, connection type |
Plugs |
| Electrical connection 1, cable outlet |
Straight |
| Electrical connection 1, connector system |
M12x1, A-coded to EN 61076-2-101 |
| Electrical connection 1, number of connections/cores |
4 |
| Electrical connection 1, type of mounting |
Screw-type lock with 18 mm hexagon and longitudinal knurl |
| Electrical connection 1, connection pattern |
00995386 |
| Electrical connection 2, connection type |
Cable |
| Electrical connection 2, connector system |
Screw terminal |
| Operational voltage range DC |
030 |
| Current rating at 40° C |
4 |
| Immunity to surge |
2.5 |
| Cable fitting |
Pg7 |
| Permissible cable diameter |
46 |
| Connection cross section |
0.75 |
| Degree of protection |
IP65IP67 |
| Ambient temperature |
-2585 |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Note on materials |
RoHS-compliant |
| Pollution degree |
3 |
| Material housing |
PA |
| Material union nut |
PA |
| Material electrical contact |
BrassWhite bronze coated |
