| Technical Data |
|
| Based on standard |
EN 61076-2-101 |
| Explosion protection |
The information in the certificate must be observed!Zone 1 (ATEX)Zone 2 (ATEX)Zone 21 (ATEX)Zone 22 (ATEX) |
| Mounting position |
optional |
| Product weight |
38 |
| Electrical connection |
4-pinSpring-loaded terminalM12x1Straight plug |
| Plug encoding |
A |
| Operational voltage range DC |
030 |
| Current rating at 40° C |
4 |
| Permissible cable diameter |
48 |
| Connection cross section |
0.140.5 |
| Degree of protection |
IP65IP67 |
| Ambient temperature |
-4085 |
| LABS (PWIS) conformity |
VDMA24364-B2-L |
| Note on materials |
RoHS-compliant |
| Pollution degree |
3 |
| Corrosion resistance class CRC |
0 - No corrosion stress |
| Material housing |
Die-cast zincNickel-plated |
| Material electrical contact |
BronzeBronze |
