SKU: 552836
GTIN: 4052568052850
Характеристики
| Measurement method | Diffuse sensor |
| Operating distance | 140 |
| Head size | M6 |
| Fibre-optic - special feature | Standard |
| Min. object diameter | 0.1 |
Все характеристики
| Technical Data | |
| Note on materials | RoHS-compliant |
| Measurement method | Diffuse sensor |
| Min. object diameter | 0.1 |
| Fibre-optic - special feature | Standard |
| Operating distance | 140 |
| Ambient temperature | -5570 |
| Head size | M6 |
| Fibre-optic length | 2 |
| Min. bending radius | 25 |
| Max. tightening torque | 3 |
| Outside diameter | 2.2 |
| Material housing | Copper alloyPVCNickel-plated |
| Material fibre-optic | PE |
| Degree of protection | IP66 |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
Приемущества
| Cable connection, push-in connector |
Документы
| SOE4_EN.PDF |
| SOEX_EN.PDF |
| Datasheet |
