| Technical Data |
|
| Exhaust-air function |
Metered blowing |
| Symbol |
00991454 |
| Operating pressure |
010 |
| Flow rate to atmosphere |
120 |
| Standard nominal flow rate (standardised to DIN 1343) |
120 |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364 zone III |
| Sound pressure level |
90 |
| Ambient temperature |
-1050 |
| Product weight |
240 |
| Pneumatic connection |
Female thread G1/4 |
| Note on materials |
RoHS-compliant |
| Material housing |
Wrought aluminium alloy |
