| Technical Data |
|
| Volume |
20 l |
| Mounting position |
Condensate drain underneath |
| Conforms to standard |
EN 286-1 |
| Symbol |
00991474 |
| Operating pressure |
-13.775232 |
| CE mark (see declaration of conformity) |
In accordance with EU Directive on Simple Pressure Vessels |
| Operating medium |
Compressed air to ISO 8573-1:2010 [-:-:-]Nitrogen |
| Corrosion resistance class CRC |
4 - Very high corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Media temperature |
-10100 |
| Ambient temperature |
-10100 |
| Max. tightening torque for connecting thread |
130 |
| Max. tightening torque for condensate drain |
27 |
| Product weight |
9000 |
| Type of mounting |
With through-hole |
| Condensate drain connection |
G3/8 |
| Pneumatic connection |
G1 |
| Material air reservoir |
Powder-coated steel |
