| Technical Data |
|
| Volume |
0.4 l |
| Mounting position |
optional |
| Conforms to standard |
AD 2000 |
| Symbol |
00991528 |
| Operating pressure |
-13.78232 |
| Approval |
CRNGerman Technical Control Board (TÜV) |
| Certificate issuing authority |
TSSACRN0H17477.5C |
| Operating medium |
Compressed air to ISO 8573-1:2010 [-:-:-]Nitrogen |
| Corrosion resistance class CRC |
3 - high corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Suitable for use with food |
See supplementary material information |
| Media temperature |
-10100 |
| Ambient temperature |
-10100 |
| Max. tightening torque for connecting thread |
23 |
| Product weight |
543 |
| Type of mounting |
Via fixing clips |
| Pneumatic connection |
G1/4 |
| Note on materials |
RoHS-compliant |
| Material air reservoir |
High-alloy stainless steel |
| Material fixing clips |
High-alloy stainless steel |
