SKU: 8126915

GTIN: 4052568560928

Все характеристики

Technical Data
Number of function keys	20
Number of system LEDs	5
Display	LCD displayWith backlighting
Display characteristics	Touchscreen
Display size	7"
Operator controls	Touch sensitive keyboardEnable control unitEmergency stop button
Input current	<= 5.6 A
Operational voltage range DC	19.230
Display resolution	WSVGA, 600x1024 pixels
Approval	CCCRCM trademarkc UL us listed (OL)
KC mark	KC-EMV
CE mark (see declaration of conformity)	To EU EMC DirectiveTo EC Machinery DirectiveIn accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)	To UK instructions for EMCTo UK regulations for machinesTo UK RoHS instructions
Certificate issuing authority	UL E239998
LABS (PWIS) conformity	VDMA24364 zone III
Storage temperature	-2070
Relative air humidity	5 - 95%
Degree of protection	IP65
Note on degree of protection	When USB cover flap is closedIn assembled state
Protection class	III
Ambient temperature	040
Product weight	950
Electrical power consumption	12
IP address allocation	FCTDHCP
Nominal operating voltage DC	24
Power failure bridging	10
Nominal altitude of use	<= 2000 m NHN
Power supply, function	Enable controlEmergency stopPower supply
Power supply, connection type	Socket strip
power supply, connection system	Socket strip 12 pin, 2 rows
Power supply, number of pins/wires	12
Power supply, assigned pins/wires	6
USB interface, connection technology	USB 2.0 type A
USB interface, plug pattern	00995868
Ethernet interface, protocol	TCP/IP
Ethernet interface, function	DiagnosticsNetwork connection to PLCParameterisation
Ethernet interface, connection type	Socket
Ethernet interface, connection system	RJ45
Ethernet interface, number of pins/wires	8
Ethernet interface, transmission rate	100 Mbit/s
Ethernet interface, connection pattern	00995789
Note on materials	RoHS-compliant
Material housing	ABS
Dimensions (W x L x H)	212 x 251 x 73 mm
Note on permissible current load at 40°C	10 – 1000 mA at each contact for emergency stop< 500 mA for enable control unit
Utilisation category	DC-13, emergency stop
Service life characteristic value B10D, subcomponent	0,25 Mio SP, emergency stop1 million switching cycles, enable control unit
