SKU: 8207226
GTIN: 4052568651855
Все характеристики
| Technical Data | |
| Size | 16 |
| Mounting position | optional |
| Design | For grippers |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Ambient temperature | -550 |
| Product weight | 42 |
| Type of mounting | Screwed to gripper |
| Note on materials | RoHS-compliant |
| Material gripper jaws | Anodised wrought aluminium alloy |
| Material cap | POM |
| Material plate | Anodised wrought aluminium alloy |
| Material screws | Galvanised steel |
| Material centering pins | Steel |
| Gripper finger material | Wrought aluminium alloy, anodised |
Приемущества
| Suitable for human-robot collaboration to ISO 15066 |
| Easy to replace the gripper finger pads in the event of wear |
| Can be mounted on pneumatic gripper/valve combination HPPH |
Документы
| HPPH_EN.PDF |
| Datasheet |
