| Technical Data |
|
| Size |
6 |
| Grid dimension |
62 |
| Exhaust-air function |
Without flow control option |
| Type of actuation |
Electric |
| Mounting position |
optional |
| Selection of additional functions |
With silencer |
| Series |
MS |
| Manual override |
DetentingNon-detenting |
| Design |
Poppet valve, electrically actuated |
| Type of reset |
Mechanical spring |
| Type of piloting |
Pilot actuated |
| Pilot air supply |
Internal |
| Symbol |
00997398 |
| Valve function |
3/2-way, closed, monostable |
| lap |
Underlap |
| Switching position indicator |
With accessories |
| Operating pressure |
37 |
| b value |
0.46 |
| C value |
23.9 |
| Standard nominal flow rate, exhaust 0.6->0 MPa (6->0 bar, 87->0 psi) |
4000 |
| Standard nominal flow rate (standardised to DIN 1343) |
5000 |
| Switch-on time |
31 |
| Characteristic coil data |
24 V DC: 2.3 W |
| Permissible voltage fluctuations |
+/- 10 % |
| Operating medium |
Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium |
Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC |
1 - Low corrosion stress |
| LABS (PWIS) conformity |
VDMA24364-B1/B2-L |
| Suitability for the production of Li-ion batteries |
Suitable for battery production according to the Festo internal definition of the degree of severity F1A with restrictions regarding the use of Cu/Zn/Ni |
| Cleanroom class |
Class 7 according to ISO 14644-1 |
| Storage temperature |
-1060 |
| Media temperature |
-550 |
| Degree of protection |
IP65 |
| Ambient temperature |
-550 |
| Product weight |
499 |
| Electrical connection |
Type CTo EN 175301-803 |
| Signal status display |
With accessories |
| Type of mounting |
Via wall/surface bracket |
| Pneumatic connection, port 1 |
G1/2 |
| Pneumatic connection, port 2 |
G1/2 |
| Pneumatic connection, port 3 |
G1/2 |
| Note on materials |
RoHS-compliant |
| Material seals |
HNBRNBR |
| Material housing |
PA-reinforced |
