SKU: 538681
GTIN: 4052568176396
Все характеристики
| Technical Data | |
| Type of actuation | Electric |
| Mounting position | Vertical +/-5° |
| Manual override | Non-detenting |
| Condensate drain | Fully automatic |
| Design | External, electric, fully automatic |
| Measured variable | Level |
| Valve function | 3/2-way, closed, monostable |
| Operator controls | Touch sensitive keyboardWith test button |
| Ready status indication | LED |
| Switching status indication | LED |
| Operating pressure | 0.816 |
| Alarm output | Contacting |
| Nominal operating voltage DC | 24 |
| Nominal rating of condensate drain | 2 |
| Approval | C-Tick |
| KC mark | KC-EMV |
| CE mark (see declaration of conformity) | To EU EMC Directive |
| UKCA marking (see declaration of conformity) | To UK instructions for EMCTo UK RoHS instructionsTo UK regulations for electrical equipment |
| Operating medium | Compressed air to ISO 8573-1:2010 [-:-:-] |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B1/B2-L |
| Storage temperature | -1060 |
| Media temperature | 160 |
| Degree of protection | IP65To IEC 60529 |
| Protection class | III |
| Ambient temperature | 160 |
| Product weight | 700 |
| Electrical connection | Screw terminal |
| Type of mounting | In-line installation |
| Condensate drain connection | PK-8 |
| Pneumatic connection | G1/2 |
| Material condensate container | Wrought aluminium alloy |
| Note on materials | RoHS-compliant |
| Material housing | Polymer |
Приемущества
| Fully automatic condensate drain with independent electric controller |
| Interface available for communicating with master control device |
| Reliable thanks to contactless capacitive sensor |
| Can be used with service units or simply in piping systems |
| Ready status and switching status indicated via LEDs and electrical interface |
